STIHL BT 230 Earth Auger-with drill bit
BT 230 Earth Auger-with drill bit
| Parameter | Specification |
|---|---|
| Displacement | 40.2 cc |
| Engine power | 1.55 kW (2.1 HP) |
| Fuel tank capacity | 0.81 L |
| Weight (powerhead only) | 10.9 kg |
| Max. engine speed | 8 500 rpm |
| Auger bit connection | 20 mm standard |
| Compatible auger diameters | 150 mm / 200 mm / 250 mm / 300 mm |
| Gearbox lubrication | STIHL gear lubricant |
| Drive type | Spur‑gear, grease‑lubricated |
| Starting system | Recoil starter |
| Typical drilling depth | Up to 300 mm (12″) |
LARGE-AREA SUPPORT CUSHION
FOR GOOD CONTROL. With the large-area support cushion, you can guide your earth auger smoothly and precisely. The cushion fits comfortably against your body during drilling, providing optimal hold and good guidance.
4-MIX® engine
The 1.4 kW STIHL 4-MIX® engine combines the advantages of a two-stroke and a four-stroke engine - it is economical, smooth, responsive and powerful. It produces less emissions and doesn't need an oil service.
Long-life air filter system
Together with the compensator that is integrated into the carburettor, the long-life air filter system offers long cleaning intervals and reliable engine protection.
QUICKSTOP DRILL BRAKE
FOR SAFE WORK. The QuickStop drill brake stops the drill if your earth auger gets stuck in the ground and causes the trigger lever to hit your thigh. The braking device ensures that the engine no longer transmits its force to the drill element, while the engine and drill element remain coupled. This means that you can simply unscrew the jammed drill in an anti-clockwise direction.
Vibration dampening frame
The vibration-dampening frame with four vibration elements provides comfortable working and reduces fatigue when drilling. The engine is positioned separately from the handle frame, allowing easier working over longer periods.
Multi-function handle
All operating elements for the engine control are integrated into the right-hand handle, enabling the drill to be operated by finger pressure. The hand always remains in a working position. BT 131 Earth Auger
Select Drill Bit Size
From $371.43
STIHL BT 230 Earth Auger-with drill bit—
$371.43
